FEATURES:
-
Circular, horizontal & elliptical polarizations
-
Multi-bay systems available
-
Low, medium and high power systems
-
Multi-Channel Systems
-
Omni directional systems
-
Custom directional patterns available
|
Specifications |
|
|
Model |
FM-P |
|
Frequency |
87-108 MHz |
|
Input Power Rating |
5 kW- 60 kW |
|
Polarization |
Circular, Elliptical & Horizontal Polarizations available |
|
Azimuth |
± 2 dB free space |
|
VSWR |
1.3 : 1 or better |
|
Connections Available |
EIA: 1-5/8”, 3-1/8”, 4-1/16”, 6-1/8” |
|
Standard Models |
|||
|
Model |
Power Rating |
Power Gain |
dB gain |
|
FM-P-CP-1 |
10-30 kW |
1.82 |
2.60 |
Notes:
-
>10 kW ratings available upon engineering review
-
Includes standard mounting brackets and attachment hardware
-
Antenna weight and wind load are approximate values for a typical structure. Final design loads may vary for the specific application.
Disclaimer: Specifications are subject to change without notice. Information may be changed or updated without notice. American Amplifier Technologies may also make improvements and/or changes to the products described at any time.
