V80 UPS Series

  • Sale
  • Regular price $470.00


V80 is a pure sine wave line interactive UPS that protects critical data and equipment form power problems while supplying clean and reliable network grade power.

V80 units have the highest efficiency ratings available, providing utility cost savings at all load levels. V80 design provides flexible mounting including tower, wall and rack mounting. V80 models combine high performance with value pricing.

Product Snapshot

  • Available Models: 700VA, 1000VA, 1500VA, 2000VA
  • Pure sine wave output
  • Automatic voltage regulation (AVR)
  • UL and cUL listed, RoHS compliant
  • 3 years electronics, 3 years battery warranty (USA and Canada)
Features:
  • Ease of use - plug and play functionality means the UPS is ready to start backing up your equipment right out of the box
  • Auto restart - after full battery discharge, the V80 automatically restarts when utility power returns
  • 96% efficient operation - high efficiency ECO mode lowers energy consumption
  • Sleek design - modern and compact, perfect for use in any home office or small office setting
  • Smart LCD display - vital monitoring and precise information from the front panel
  • Maintenance bypass - an optional XBDM bypass module enables the V80 to be serviced or replaced without interruption of power to critical loads
  • $50,000 load protection policy - protection against damaged connected equipment


MODEL NUMBER V80-700 V80-1000 V80-1500 V80-2000
INPUT Capacity 700VA (420W) 1000VA (600W) 1500VA (900W) 2000VA (1200W)
Voltage range 82–148VAC
Frequency 50/60Hz auto-sensing
OUTPUT Voltage 120VAC
Waveform Pure sine wave
Transfer time (typical) 2-6 ms
Efficiency Up to 96% ECO mode, 93% buck and boost mode
Harmonic distortion 2% @ 100% linear load; 5% @ 100% non-linear load
BATTERY Battery quantity and size (1) 12V 9AH (2) 12V 7AH (2) 12V 9AH
Battery type Sealed, maintenance-free lead acid
Charge current 1A max
Recharge Typically < 4 hours to 90% capacity
PHYSICAL Dimensions (W x D x H) 17.2 x 16.1 x 3.5
Weight 24 lbs 27.3 lbs 29.3 lbs 31.3 lbs
Line cord 6 ft, C13 to 5–15P  C19 to 5-20P
Receptacles (8) NEMA 5–15R
ENVIRONMENT Operating temperature 32–104°F (0–40°C)
Audible noise < 40dBA  < 45dBA
Altitude 11,500 ft above sea level
APPROVALS UL, cUL, RoHS
WARRANTY 3 years electronics, 3 years battery warranty (USA and Canada)
COMMUNICATIONS INTERFACE USB
INCLUDED IN BOX 5-15P line cord, tower pedestals, user manual, USB cable, Xtreme Power Monitor software
AVAILABLE OPTIONS 5 year extended warranty, bypass distribution (XBDM), power distribution (XPDU), 4-post rail kit, 2-post shelf kit, wall mount bracket
