S70 Line Interactive UPS series

  • Sale
  • Regular price $200.00

Power quality disturbances including voltage fluctuations, over voltage, under voltage, and voltage blackouts occur unexpectedly. In the event of any of these common power problems, the S70 UPS activates to protect all connected critical loads—ranging from your computer to your business telephone system.

The S70 streamlines installation to just a few simple steps, allowing backup power protection right out of the box. The smart LCD screen offers real-time monitoring of UPS parameters while shutdown and monitoring software enables UPS and remote device control over your network.

Product Snapshot

  • Available models: 500VA, 700VA, 1000VA, 1500VA, 2000VA
  • Smart LCD display
  • Auto restart
  • Automatic voltage regulation (AVR)
  • UL and cUL listed, RoHS compliant
  • Primary applications: home or small office, desktop computers, routers, and switches
  • 3 years electronics, 3 years battery warranty (USA and Canada)
MODEL NUMBER S70-500 S70-700 S70-1000 S70-1500 S70-2000
INPUT Capacity 500VA (300W) 700VA (420W) 1000VA (600W) 1500VA (900W) 2000VA (1200W)
Voltage 120VAC
Frequency 60Hz
OUTPUT Voltage 120VAC
Waveform Sine wave (normal), simulated sine wave (battery mode)
Frequency 60Hz ± 1Hz
Transfer time 4ms (typical)
BATTERY Battery type Sealed, maintenance-free lead acid
Battery quantity and size (1) 12V 7AH (1) 12V 9AH (2) 12V 7AH (2) 12V 9AH
Recharge 4–6 hours to 90% capacity
PHYSICAL UPS dimensions (W x D x H) 3.9 x 11.3 x 5.6 in 5.7 x 13.8 x 6.3 in 5.7 x 15.6 x 8.1 in
Shipping dimensions 5.5 x 13.1 x 8.7 in 7.5 x 17.4 x 10 in 9.1 x 19.3 x 11.3 in
UPS weight 9.5 lbs 10.8 lbs 17.6 lbs 24.5 lbs 25.4 lbs
Shipping weight 10.1 lbs 11.5 lbs 19.4 lbs 27.1 lbs 28.0 lbs
Line cord 5 ft 5–15P C13 to 5–15P* 5 ft 5–15P 4 ft 5–15P 4 ft 5–20P
Receptacles (4) 5–15R (6) 5–15R (8) 5–15R
Cooling Convection cooled Fan cooled
ENVIRONMENT Operating temperature 32–104°F (0–40°C)
Humidity 0–90%
Altitude 11,500 ft above sea level
INDICATORS & ALARMS LCD display AC mode, battery mode, load/battery level, input/output voltage, overload fault, low battery
Data line protection N/A RJ45
WARRANTY 3 years electronics, 3 years battery (USA and Canada)
INCLUDED IN BOX Shutdown and monitoring software, USB cable, user manual
